Medium Power Amplifier
- Medium power output between 20dBm and 30dBm
- Excellent gain flatness
- Excellent Amplitude flatness
- High frequency up to 50GHz
All products can be customized according to customer needs.
Product Parameter
| Part Number | Freq Min (G) | Freq Man (G) | Gain (dB) | Output Power for (P1dB) (dBm) | Psat (dBm) | Noise Figure (dB) | Output IP3 (dBm) | Input Max Power (no damage)(dBm) | VSWR | Bias Voltage | In/Out Port | Inventory | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MZMPA00130GS15 | 0.1 | 30 | 15 | 20 | 21 | 5 | 30 | 20 | 2 | 16 | K-Female | ||
| PA00118GA0.5W | 0.1 | 18 | 35 | 26 | 28 | 5 | 5 | 2 | 20 | SMA-Female | |||
| MZPA00118GA0.25W | 0.1 | 18 | 35 | 24 | 29 | 5 | 5 | 2.2 | 20 | SMA-Female | |||
| MZPA000308GA0.5W | 0.03 | 8 | 30 | 27 | 28 | 4 | 5 | 2 | 15 | SMA-K | |||
| MZPA00051200GA0.9W | 0.05 | 12 | 30 | 28.5 | 31 | 8 | 5 | 2 | 28 | SMA-Female | |||
| MZMPA008038GA0.5W | 0.8 | 3.8 | 27 | 24 | 6 | 40 | 5 | 2.2 | 15 | SMA-K | |||
| MPA1840GA0.2W | 18 | 40 | 25 | 23 | 33 | 0 | 2.5 | 15 | 2.92mm-Female | ||||
| MZMPA1850GA0.5W | 18 | 50 | 35 | 24 | 27 | 5 | 30 | 0 | 2.5 | 18 | 2.4mm-Female | ||
| MZMPA09096GA0.5W | 9 | 9.6 | 26 | 26 | 27 | 3.8 | 5 | 2 | SMA-F | ||||
| MZMPA085096GA17 | 8.5 | 9.6 | 20 | 21 | 22 | 28 | 10 | 2 | 15 | SMA-K | |||
| MZMPA08510GA17 | 8.5 | 10 | 20 | 21 | 22 | 28 | 10 | 2 | 15 | SMA-K | |||
| MPA00220GA0.5W | 0.2 | 20 | 35 | 26 | 27 | 32 | 3 | 2.5 | 24 | SMA-Female | |||
| MPA1850GA0.5W-SR | 18 | 50 | 35 | 24 | 27 | 5 | 30 | 0 | 1.8 | 2.4mm-Female | |||
| MZMPA0118GA25 | 1 | 18 | 25 | 29 | 29 | 40 | 10 | 1.5 | SMA-Female | ||||
| MZPA0040045GA1W | 0.4 | 0.45 | 20 | 30 | 31 | 15 | 2.5 | 15 | SMA-Female | ||||
| MZMPA2331GA50 | 23 | 31 | 50 | 18 | 20 | 4 | -20 | 1.8 | 2.92mm-Female | ||||
| MZPA0040045GA1W | 0.4 | 0.45 | 20 | 30 | 31 | 15 | 2.5 | 15 | SMA-Female | ||||
| MZPA18265GA0.5W | 18 | 26.5 | 40 | 25 | 30 | 5 | 2 | 15 | SMA-Female | ||||
| MZPA0118GA25 | 1 | 18 | 25 | 27 | 28 | 5 | 40 | 10 | 2 | 15 | SMA-Female | ||
| MZPA0218GA0.6W | 2 | 18 | 25 | 28 | 30 | 38 | 5 | 2.5 | 15 | SMA-Female | |||
| MZPA0250GA1W | 2 | 50 | 25 | 30 | 31 | 13 | 37 | 20 | 3 | 2.4mm-K | |||
| MZPA0812GA0.6W | 8 | 12 | 33 | 28 | 29 | 5 | 5 | 2 | 15 | SMA-Female | |||
| MZPA1840GA0.3W | 18 | 40 | 35 | 24 | 25 | 5.5 | -2 | 2 | 15 | 2.92mm-Female | |||
| MZPA1743GA1W | 17 | 43 | 21 | 30 | 31 | 15 | 2 | 15 | 2.92mm-Female | ||||
| MZPA1743GB0.3W | 17 | 43 | 18 | 24 | 25 | 10 | 2 | 15 | 2.92mm-Female | ||||
| MZPA1823GA1.5W | 18 | 23 | 21 | 30 | 32 | 15 | 2 | 15 | 2.92mm-Female | ||||
| MZPA1840GA0.5W | 18 | 40 | 35 | 27 | 28 | 7.5 | 0 | 2 | 15 | 2.92mm-Female | |||
| MZPA1840GA1W | 18 | 40 | 21 | 30 | 31 | 15 | 2 | 15 | 2.92mm-Female | ||||
| MZPA1840GB0.3W | 18 | 40 | 17 | 22 | 23 | 11 | 2 | 15 | 2.92mm-Female | ||||
| MZPA1840GB0.5W | 18 | 40 | 33 | 27 | 28 | 0 | 2 | 15 | 2.92mm-Female | ||||
| MZPA1840GS0.3W | 18 | 40 | 17 | 22 | 23 | 5 | 15 | 2.5 | 15 | 2.92mm-Female | |||
| MZPA1843GB0.3W | 18 | 43 | 18 | 25 | 26 | 10 | 2 | 15 | 2.92mm-Female | ||||
| MZPA2335GA0.5W | 23 | 35 | 20 | 28 | 29 | 15 | 2 | 20 | 2.92mm-Female | ||||
| MZPA2731GA0.5W | 27 | 31 | 25 | 27 | 28 | 5 | 2 | 12 | 2.92mm-Female | ||||
| MZPA1840GB0.5W-SR | 18 | 40 | 33 | 27 | 28 | 0 | 2 | 15 | 2.92mm-Female | ||||
| MZPA0118GAC20 | 1 | 18 | 24 | 25 | 26 | 4 | 36 | 10 | 2 | 2.92mm-Female | |||
| MZPA1840GAC0.5W | 18 | 40 | 25 | 26 | 27 | 36 | 10 | 2.5 | 2.92mm-Female | ||||
| PA3236GA0.5W | 32 | 36 | 26 | 26 | 27 | 10 | 5 | 2 | 2.92mm-Female | ||||
| PA000200GA0.5W | 0.05 | 20 | 20 | 25 | 27 | 10 | 1.8 | SMA-Female | |||||
| PA286291GA0.5W | 28.6 | 29.1 | 22 | 28 | 29 | 12 | 1.8 | 2.92mm-Female | |||||
| PA199214GA1W | 19.9 | 21.4 | 26 | 30 | 31 | 10 | 1.8 | SMA-Female | |||||
| PA0118GA0.3W | 1 | 18 | 25 | 25 | 27 | 32 | 3 | 1.5 | SMA-Female | ||||
| PA2331GC0.5WQ | 23 | 31 | 28 | 28 | 29 | 5 | 5 | 2 | 2.92mm-Female | ||||
| PA0140GAC1W | 1 | 40 | 25 | 28 | 29 | 13 | 37 | 20 | 1.5 | 2.92mm-Female | |||
| PA0110GA0.3W | 1 | 10 | 27 | 26 | 27 | 2.2 | 5 | 2.2 | SMA-Female | ||||
| PA0110GA0.3W-SR | 1 | 10 | 27 | 26 | 27 | 2.2 | 5 | 2.2 | SMA-Female | ||||
| PA00506GA0.5W-SR | 0.5 | 6 | 35 | 28 | 32 | 35 | 5 | 2 | SMA-Female | ||||
| PA250300GA0.4W | 25 | 30 | 27 | 25 | 26 | 6 | 5 | 2 | 2.92mm-Female | ||||
| MZPA1840GD0.5W | 18 | 40 | 35 | 28 | 29 | 6 | 0 | 2 | 2.92mm-Female | ||||
| MZPA1843GA0.3W | 18 | 43 | 35 | 24 | 25 | 5.5 | -5 | 2 | 15 | 2.92mm-Female | |||
| MZPA19521GA2W | 19.5 | 21 | 36 | 34 | 35 | 2 | 1.8 | 15 | SMA-K | ||||
| MZPA2331GA0.5W | 23 | 31 | 36 | 28 | 29 | 5 | 2 | 20 | 2.92mm-Female | ||||
| MZPA2331GA0.5WQ | 23 | 31 | 36 | 28 | 29 | 5 | 2 | 20 | 2.92mm-Female | ||||
| MZPA2335GB0.5W | 23 | 35 | 40 | 28 | 30 | 7 | 10 | 2 | 20 | 2.92mm-Female | |||
| PA2040GAC0.5W | 20 | 40 | 33 | 25 | 28 | 5 | 2 | 2.92mm-Female | |||||
| PA0120GAC0.5W | 1 | 20 | 33 | 25 | 28 | 5 | 2 | SMA-Female | |||||
| PA0308GA20W | 3 | 8 | 53 | 43 | 1.5 | SMA-Female | |||||||
| PA0204GB20W | 2 | 4 | 47 | 43 | 5 | 1.5 | SMA-Female | ||||||
| PA0204GA15W | 2 | 4 | 47 | 43 | 5 | 1.5 | SMA-Female | ||||||
| PA2030GA2W-SR | 20 | 30 | 35 | 34 | 10 | 1.5 | 2.92mm-K | ||||||
| MZPA0218GA20W | 2 | 18 | 45 | 42 | 10 | 2 | SMA-K | ||||||
| PA2244GA0.5W | 22 | 44 | 35 | 25 | 27 | 0 | 2 | 2.4mm-Female | |||||
| PA1840GBC0.5W | 18 | 40 | 35 | 27 | 28 | 6 | 0 | 2 | 2.92mm-Female | ||||
| PA0218GA10W | 2 | 18 | 35 | 41 | 10 | 2 | SMA-Female | ||||||
| PA003020GA2W | 0.3 | 2 | 35 | 34 | 42 | 5 | 2 | SMA-Female | |||||
| PA005080GA0.5W | 0.5 | 8 | 35 | 29 | 29 | 1.5 | 0 | 2.5 | SMA-Female | ||||
| PA093095GA30W | 9.3 | 9.5 | 35 | 45 | 15 | 1.5 | SMA-Female | ||||||
| PA00540GC0.1W | 0.5 | 40 | 43 | 18 | 21 | 5 | -15 | 2.5 | 2.92mm-Female | ||||
| PA040180GA10W | 4 | 18 | 45 | 41 | 5 | 2 | SMA-Female | ||||||
| PA040180GA10W-SR | 4 | 18 | 45 | 41 | 5 | 2 | SMA-Female | ||||||
| PA0206GA50W-SR | 2 | 6 | 45 | 47 | 47 | 8 | 1.5 | SMA-Female | |||||
| PA00382000GAC1W | 0.38 | 20 | 32 | 31 | 10 | 2 | SMA-Female | ||||||
| PA265400GAC1W | 26.5 | 40 | 38 | 32 | 10 | 2 | 2.92mm-Female | ||||||
| MZPA3740GS0.7W | 37 | 40 | 30 | 27 | 29 | 35 | 5 | 2 | 15 | K-Female | |||
| PA090096GA0.5W | 9 | 9.6 | 31 | 26 | 27 | 3.8 | 5 | 1.8 | SMA-Female | ||||
| PA1840GCC0.5W | 18 | 40 | 35 | 27 | 28 | 6 | 0 | 2 | 2.92mm-Female | ||||
| PA0208GA0.5W | 2 | 8 | 32 | 27 | 28 | 37 | 20 | 1.5 | SMA-K | ||||
| PA002100GA0.5W-SR | 0.2 | 10 | 30 | 25 | 3 | 2.3 | SMA-Female | ||||||
| MZPA00118GA0.5W | 0.1 | 18 | 35 | 26 | 28 | 5 | 5 | 2.2 | 20 | SMA-Female |
